Question 1

What is StoneWall Orana?

Accepted Answer

StoneWall Orana is a three-piece dry-cast concrete wall system designed for both above-grade hardscape applications and reinforced earth retention when used as an MSE (Mechanically Stabilized Earth) system.

Question 2

How does StoneWall Orana differ from StoneWall II?

Accepted Answer

StoneWall Orana uses fewer unit shapes than StoneWall II, making it simpler to install while still allowing fluid curves, efficient corners, and an ashlar-style appearance. It delivers many of the same design capabilities with a streamlined unit set.

Question 3

What finishes are available for StoneWall Orana?

Accepted Answer

StoneWall Orana is available in smooth and abraded face finishes, depending on the market and manufacturing partner.

Question 4

What alignment system does StoneWall Orana use?

Accepted Answer

StoneWall Orana uses the 3WAP (3-Way Alignment Plug) system, allowing for accurate alignment, consistent setback, and flexibility for straight, curved, and ashlar-style layouts.

Question 5

What types of projects is StoneWall Orana best suited for?

Accepted Answer

StoneWall Orana is well suited for residential retaining walls, landscape walls, terraces, garden features, and above-grade hardscape elements where both structural performance and refined aesthetics are desired.

Question 6

How do I create a column using StoneWall Orana?

Accepted Answer

Columns are created by nesting two 16/14" units and two 7/5" units together to form the 21" column core. Each course is rotated 90 degrees from the course below to maintain proper bond and alignment.
Column returns are formed using the 12/10" units. Every other return unit is cut along the top score to create an additional 7/5" unit, which maintains consistent joint offsets and a clean column appearance.

Question 7

Is StoneWall Orana suitable for retaining walls?

Accepted Answer

Yes. StoneWall Orana can be used for earth retention when designed as a reinforced MSE wall with geogrid. It can also be used for above-grade hardscape features where structural reinforcement is not required.

Question 8

How tight can I radius with StoneWall Orana?

Accepted Answer

As StoneWall Orana comprises of 3 orthogonal units, the installer has great flexibility when constructing radii.

Large units only create a 11 ft 10 inch radius

Medium units create a 8 ft 2 inch radius

Small units create a 4 ft 2 inch radius
