GravityStone® Tradition
So Simple, It's Advanced:
For over 30 years, GravityStone® has set the standard for innovation and flexibility in the segmental retaining wall industry.
GravityStone® is the 1 product that is capable of utilizing 2 structural systems, empowering designers and contractors with 6 structural solutions in commercial earth retention.
The 1-2-6 Advantage
-
GravityStone® Core (A.B.A Fat Face®) is an Segmental Retaining Wall system designed for large commercial earth retention MSE or landscape walls and small gravity wall structures
-
GravityStone® Modular SRW components can build large Multi-depth gravity structures without utilizing geogrid
-
GravityStone® Hybrid design solutions can be created by interconnecting the 2 systems - MSE and Modular. Above and below, or side by side
-
GravityStone® Slide Stop is the solution for narrow footprints on poor soil sites
-
GravityStone® BarrierWall creates double-sided, free-standing walls, fences, and parapets
Maximize the potential of YOUR building site.
Unit Details
GravityStone MSE
Core (Fat Face)
Dimensions: 18" x 8" x 10.5-12"
GravityStone Modular
Thin Face:18" x 8" x 6"
Trunk: 24" x 8" x 4"
Anchor Junction : 12" x 8" x 6"
Two Structural Systems
GravityStone® Core
Ideal for reinforced MSE Walls with unlimited height restraints, and small gravity structures.
-
Easily construct durable earth retainage
-
Concave, Convex, and 90° Corners
-
Vertical (0 degree) or Battered (4.5 degree) walls using the Reversible Alignment Plug (RAP)
-
Used in conjunction with geosynthetic allows durable Mechanically Stabilized Embankment walls
GravityStone® Modular
The ultimate Stack-n-Fill system Ideal for cut sites.
-
No Geotextile Required
-
Requires Less Excavation
-
Simple and Fast to Build
-
Vertical or Battered Walls using the Reversible Alignment Plug (RAP)
-
Concave, Convex and 90° Corners
-
Create Fences, Pillars, and Planters with the same components
The Structural Systems
M.S.E.
Modular
GravityStone Core (Fat Face) combined with geogrid is ideal for fill site applications. The system can be constructed as a vertical wall or with a 4.5° batter, depending on design requirements.
Ideal for cut sites, GravityStone Modular can interlock with the system's Trunks and Anchors to form multi-depth modular gravity walls. This configuration allows wall footprints as narrow as 30% of wall height, depending on soil and site conditions. The system can be constructed as a vertical wall or with a 4.5° batter, depending on design requirements.
Hybrid
M.S.E. Over Modular
Hybrid
Modular Over M.S.E.
Advanced Applications
Lateral Hybrid
Using GravityStone Modular in the lower portion of the wall reduces excavation and overall footprint. The wall can then transition to MSE construction once sufficient space is available behind the wall to accommodate required geogrid lengths.
Placing GravityStone Modular in the upper portion of the wall creates a large void zone for utilities, structures, or penetrations—without interfering with the reinforced MSE zone below.
GravityStone Core and Gravity Stone modular systems can be combined side-by-side, using MSE where space allows and transitioning to modular construction to navigate obstacles or where a narrower footprint is required.
